About B-Series Fittings:A one-piece non-skive crimp fitting for all braided hoses (up to 1" ID).Features:Alfagomma Top Coat Tested in accordance with ASTM B117-03 and UNI ISO 9227 standards. Over 500…
100% Secure Payment & Data Safety
Global Delivery & Fast Dispatch
30 Days Free Return & Exchange
| About B-Series Fittings: |
|---|
|
| Features: |
|
| Material: |
|
| Part Number | Hose ID Size | F Thread Dia x Pitch | Tube OD | C Cut-Off Factor |
D Drop |
CH2 | Weight | ||
|---|---|---|---|---|---|---|---|---|---|
| DashSize | (in.) | (mm) | (mm) | (mm) | (mm) | (mm) | lbs/each | ||
| B-0414-FM4L | 04 | 1/4″ | 6.4mm | 14×1.5 | 8mm | 43.0mm | 17.5mm | 17mm | 0.15 lbs |
| B-0416-FM4L | 04 | 1/4″ | 6.4mm | 16×1.5 | 10mm | 42.0mm | 20.0mm | 19mm | 0.17 lbs |
| B-0516-FM4L | 05 | 5/16″ | 7.9mm | 16×1.5 | 10mm | 47.5mm | 20.0mm | 19mm | 0.19 lbs |
| B-0616-FMOL | 06 | 3/8″ | 9.5mm | 16×1.5 | 10mm | 46.8mm | 20.0mm | 19mm | 0.21 lbs |
| B-0618-FM4L | 06 | 3/8″ | 9.5mm | 18×1.5 | 12mm | 46.8mm | 19.5mm | 22mm | 0.23 lbs |
| B-0822-FM4L | 08 | 1/2″ | 12.7mm | 22×1.5 | 15mm | 55.0mm | 21.0mm | 27.0mm | 0.35 lbs |
| B-1026-FM4L | 10 | 5/8″ | 15.9mm | 26×1.5 | 18mm | 65.3mm | 24.0mm | 32mm | 0.50 lbs |
| B-1230-FM4L | 12 | 3/4″ | 19.0mm | 30×2.0 | 22mm | 69.4mm | 32.0mm | 36mm | 0.69 lbs |
| B-1636-FM4L | 16 | 1″ | 25.4mm | 36×2.0 | 28mm | 91.4mm | 32.0mm | 41mm | 1.09 lbs |
