About B-Series Fittings:A one-piece non-skive crimp fitting for all braided hoses (up to 1" ID).Features:Alfagomma Top Coat Tested in accordance with ASTM B117-03 and UNI ISO 9227 standards. Over 500…
100% Secure Payment & Data Safety
Global Delivery & Fast Dispatch
30 Days Free Return & Exchange
| About B-Series Fittings: |
|---|
|
| Features: |
|
| Material: |
|
| Part Number | Hose ID Size | F Thread | C Cut-Off Factor |
D Drop |
CH2 | Weight | |||
|---|---|---|---|---|---|---|---|---|---|
| DashSize | (in.) | (mm) | DashSize | Size(in) – TPI | (mm) | (mm) | (mm) | lbs/each | |
| B-0404-FJ9S | 04 | 1/4″ | 6.4mm | 04 | 7/16-20 | 27.0mm | 21.0mm | 16mm | 0.14 lbs |
| B-0405-FJ9S | 04 | 1/4″ | 6.4mm | 05 | 1/2-20 | 26.5mm | 23.5mm | 17mm | 0.15 lbs |
| B-0406-FJ9S | 04 | 1/4″ | 6.4mm | 06 | 9/16-18 | 31.0mm | 23.0mm | 19mm | 0.16 lbs |
| B-0506-FJ9S | 05 | 5/16″ | 7.9mm | 06 | 9/16-18 | 31.5mm | 23mm | 19mm | 0.20 lbs |
| B-0606-FJ9S | 06 | 3/8″ | 9.5mm | 06 | 9/16-18 | 42.3mm | 23.0mm | 19mm | 0.20 lbs |
| B-0608-FJ9S | 06 | 3/8″ | 9.5mm | 08 | 3/4-16 | 48.8mm | 29.0mm | 25mm | 0.28 lbs |
| B-0806-FJ9S | 08 | 1/2″ | 12.7mm | 06 | 9/16-18 | 44.6mm | 29.0mm | 25mm | 0.32 lbs |
| B-0808-FJ9S | 08 | 1/2″ | 12.7mm | 08 | 3/4-16 | 46.4mm | 29.0mm | 25mm | 0.34 lbs |
| B-0810-FJ9S | 08 | 1/2″ | 12.7mm | 10 | 7/8-14 | 45.8mm | 32.0mm | 27mm | 0.36 lbs |
| B-0812-FJ9S | 08 | 1/2″ | 12.7mm | 12 | 1-1/16-12 | 37.3mm | 46.0mm | 32mm | 0.46 lbs |
| B-1010-FJ9S | 10 | 5/8″ | 15.9mm | 10 | 7/8-14 | 49.0mm | 32.0mm | 27mm | 0.49 lbs |
| B-1012-FJ9S | 10 | 5/8″ | 15.9mm | 12 | 1-1/16-12 | 47.9mm | 48.0mm | 32mm | 0.56 lbs |
| B-1212-FJ9S | 12 | 3/4″ | 19.0mm | 12 | 1-1/16-12 | 58.2mm | 46.0mm | 32mm | 0.70 lbs |
| B-1216-FJ9S | 12 | 3/4″ | 19.0mm | 16 | 1-5/16-12 | 53.6mm | 53.0mm | 38mm | 0.83 lbs |
| B-1616-FJ9S | 16 | 1″ | 25.4mm | 16 | 1-5/16-12 | 74.0mm | 56.0mm | 38mm | 1.14 lbs |
